1. Watch the NASA video “What are sunspots?”
Show students the NASA video “What are sunspots?” Provide support for vocabulary terms sunspots, magnetic field, photosphere, convection, and atmosphere, as needed. Then check students’ understanding. Ask students to restate the comparison of sunspots to light bulbs in their own words.
2. Introduce the activity and safety concerns.
Explain to students that looking directly at the sun is very dangerous and can cause permanent damage to human eyes. Make sure that students understand that no one—not even scientists—ever look directly at the sun. Instead, scientists use methods that allow them to observe the sun indirectly. In this activity, students will build a pinhole viewer that will allow them to observe the sun indirectly and safely.
3. Have students build a pinhole viewer to view sunspots.
Divide students into small groups of 3 or 4. Before students begin, project the stepbystep illustration for them to refer to as they build their viewers.
 Take the cardboard box and cut a 2 centimeter x 2 centimeter hole at one end.
 Tape a piece of aluminum foil over the hole, making sure it is taut.
 Carefully use the pushpin or sewing needle to poke a hole into the foil.
 At the opposite side of the box, cut a small window about 1 centimeter from the end. The window should be no larger than 10 centimeters x 3 centimeters. Make sure that the window is no wider than the side of the box.
 Tape a piece of white paper to the inside of the box. This will be your viewing screen.
 Aim the pinhole side of the projector at the sun. Keep positioning the projector until you have the image of the sun on your screen. It will appear to be a white disk.
4. Have students make a math connection.
Tell students that they can gather data from their sunspot viewer activity to calculate, or figure out, the diameter of the sun. First model, and then have them do the following steps in order:
 Draw a circle around the image of the projected sun on the paper. Find the center of the circle by folding the circle twice making sure the outer edges of the circle line up. For a more precise method, students can use the chord bisector method, described below. Place a dot in the exact center of the circle.
 Draw any two chords, or line segments that cross in two places on the circumference of the circle.
 Draw a line segment perpendicular (at a 90° angle) to the chord toward the center of the circle.
 Repeat with the second chord.
 Find the center of the circle at the point where the two perpendicular lines drawn intersect or cross.
 Then, use a ruler to measure the distance from the center of the circle to one side of the circle in centimeters. This is the radius of the circle. Multiply the radius by 2 to calculate the diameter.
 Use a ruler to measure the distance from the pinhole to the paper. The pinhole is on the opposite side of the box from the paper. Calculate the distance by measuring the length of the box. Measure using centimeters.
 Finally, use this formula: Diameter of the image of the sun ÷ distance from the pinhole to the paper × distance from Earth to sun, approximately 149,600,000 kilometers (92,957,130 miles) = diameter of the sun
Note that students should arrive at a result for the diameter of the sun that is approximately 1.4 million kilometers (870,000 miles). Explain the relative size of the Earth and the sun. Tell students that the sun’s diameter is about 100 times that of the Earth.
5. Have students use their pinhole camera to track sunspots over a period of time.
Explain to students that sunspots can serve as markers to help us see the sun’s rotation. Distribute one copy of the worksheet Sunspot Mapping Grid to each group. Ask groups to sketch and label each sunspot for 10 days.
6. Have a wholeclass discussion about what students observed over time.
After students have tracked sunspots for ten days, have a wholeclass discussion about what they observed. Ask:
 Have the sunspots moved? Describe their movement.
 Have the shapes and sizes of the sunspots changed? How?
 Are there fewer sunspots or more sunspots? Why do you think that is?
 What did you learn about the sun’s rotation by tracking sunspots over time?
Students should understand that the sun rotates, which causes sunspots to vary over time in a regular and somewhat predictable way.
Informal Assessment
Have each student write a brief paragraph defining what sunspots are and explaining what can be learned about the sun's rotation by tracking sunspots. Encourage students to use vocabulary terms sunspots, magnetic field, and photosphere in their paragraphs.
Extending the Learning
Have students use the National Geographic sun interactive The Center of it All to learn more about surface features of the sun, such as sunspots, solar flares, and solar prominences.
Subjects & Disciplines

Earth Science
 Astronomy
 Experiential Learning
 Mathematics
Learning Objectives
Students will:
 explain the importance of safety when observing the sun
 gather data and calculate the diameter of the sun
 track sunspots and make observations about them
Teaching Approach
 Learningforuse
Teaching Methods
 Cooperative learning
 Discussions
 Handson learning
 Inquiry
Skills Summary
This activity targets the following skills:

21st Century Student Outcomes
 Learning and Innovation Skills

Critical Thinking Skills
 Analyzing
 Creating
 Understanding
Connections to National Standards, Principles, and Practices
NCTM Principles and Standards for School Mathematics
 Algebra (68) Standard 4: Analyze change in various contexts
 Data Analysis & Probability (68) Standard 2: Select and use appropriate statistical methods to analyze data
 Geometry (35) Standard 2: Specify locations and describe spatial relationships using coordinate geometry and other representational systems
National Science Education Standards
 (58) Standard B3: Transfer of energy
 (58) Standard D3: Earth in the solar system
 (K4) Standard D2: Objects in the sky
ISTE Standards for Students (ISTE Standards*S)
 Standard 2: Communication and Collaboration
What You’ll Need
Materials You Provide
 Aluminum foil
 Pencils
 Rulers
 Sewing needles or push pins
 Shoeboxes, or 2foot rectangular cardboard boxes
 Telescope or binoculars
 Transparent tape
 White paper
 White poster board
Required Technology
 Internet Access: Required
 Tech Setup: 1 computer per classroom, Projector, Speakers
 PlugIns: Flash
Physical Space
 Classroom
 Outdoor natural environment
Setup
Open space
Grouping
 Smallgroup instruction
Other Notes
Ideally, this activity will take place over ten days.
Background Information
The sun is responsible for all life on Earth; it gives us light and heat. The sun is not a solid body; it is a giant ball of gas, made mostly of hydrogen and helium. The surface of the sun is called the photosphere. Sunspots are cooler regions on the sun, caused because of a strong magnetic field. Sunspots appear dark only because they are not as hot or bright as the area surrounding them. The average surface temperature of the sun is 6,273 Kelvin (6,000 degrees Celsius). Sunspots are about 4,773 Kelvin (4,500 degrees Celsius).
Prior Knowledge
 None
Recommended Prior Activities
 None
Vocabulary
straight line segment joining and included between two points on a circle.
transfer of heat by the movement of the heated parts of a liquid or gas.
width of a circle.
scale for measuring temperature where zero Kelvin is absolute zero, the absence of all energy.
area around and affected by a magnet or charged particle.
lowest visible layer of a star and the boundary from which the star's diameter is measured.
dark, cooler area on the surface of the sun that can move, change, and disappear over time.
Websites
 High Altitude Observatory (HAO): Questions and Answers About the Sun
 NASA: Solar and Heliospheric Observatory (SOHO)
 National Solar Observatory
 National Geographic Science: Space
 NASA: Living with a Star—The SunEarth Connection
 Solar and Heliospheric Observatory (SOHO): Real Time GIF Movies
 Solar and Heliospheric Observatory (SOHO): Our Star the Sun
 Stanford Solar Center
 National Geographic Science: The Sun—Living With a Stormy Star
 Nat Geo Movies: Wildest Weather in the Solar System
Tips & Modifications
Tip Safety
Periodically remind students to never look directly at the sun. Make sure students understand they can cause irreversible damage to their eyes without using the proper equipment and techniques to view the sun.
Modification
Simplify Step 4 for students in younger grades. Instead of using the chord bisector method, have them trace, cut, and fold the circle in half. Then measure that line to establish diameter.
